Semiconductor Sector
Plasma Quest work with many semiconductor fabrication centres
- Excellent run to run reproducibility
- Excellent wafer uniformity
- Multi-wafer cassette options available
- Deposition onto multiple wafer sizes
- Plasma treatment
- Wafer etching capability
- Compatible with photoresist
- Plasma treatment developed during the InREP project enabled ohmic contact of AZO to doped GaN
